Licenses

Generate, manage, and export license keys with advanced customization, bulk operations, and inline editing capabilities.

License Generation

Atlas provides comprehensive license generation with full control over format, duration, and access levels.

Basic Generation Process

1. Click Create License in the Licenses tab
2. Set the number of licenses to generate (1-10,000)
3. Select duration type: Hours, Days, Weeks, Months, Years, or Lifetime
4. Enter duration value (ignored for Lifetime licenses)
5. Assign a level value (1-100) for permission tiers
6. Add optional notes or descriptions
7. Click Generate to create licenses

Advanced Customization

Feature	Description	Example
Custom Mask	Define license key format using pattern characters	KEY-****-#### ATLAS-***-***-***
Charset	Select which characters to include in generation	Uppercase (A-Z), Lowercase (a-z), Numbers (0-9), Special
Duration	Time until license expires after first use	30 Days, 1 Year, Lifetime
Level	Permission tier for feature gating	1 (Basic), 50 (Pro), 100 (Enterprise)
Notes	Internal notes or customer information	"Customer: John Doe", "Order #12345"

License Management

Inline Editing

Edit license properties directly in the table without opening modal dialogs:

• Expiry Date - Click to open date picker and modify expiration
• Note - Double-click to edit description text
• Level - Double-click to change permission level (1-100)

Individual License Actions

Action	Function
Reset License	Clear HWID and IP bindings, allowing the license to be used on new hardware or from a different location
Ban License	Create a ban entry for this license key, immediately denying all authentication attempts
Pause/Suspend	Temporarily disable the license. While suspended, all authentication attempts are denied. Toggle again to resume.
Delete	Permanently remove the license from your application

Bulk Operations

Select multiple licenses using checkboxes to perform batch operations:

Export System

Export license data in customizable formats for external use:

Column Selection

Choose which fields to include in your export:

• License Key - The unique license identifier
• Note - Internal notes or descriptions
• Level - Permission tier (1-100)
• Expiry Date - When the license expires
• Hardware ID (HWID) - Bound device identifier
• IP Address - Last connection IP
• Location - Geographic location from IP
• Last Login - Most recent authentication timestamp
• Device - Device information string

Delimiter Options

Delimiter	Format	Use Case
Comma	key1,note1,level1	Standard CSV format for spreadsheets
Newline	key1\nkey2\nkey3	One key per line for simple lists
Semicolon	key1;note1;level1	Alternative CSV for EU locales
Tab	key1\tnote1\tlevel1	TSV format for easy spreadsheet import
Pipe	key1|note1|level1	Pipe-delimited for data processing

Export Scope

• Export Selected - Export only licenses with checked checkboxes
• Export All - Export entire license list regardless of selection

License Table Columns

The license management table displays comprehensive information:

Column	Information
License Key	Unique identifier used for authentication
Note	Internal notes, customer info, or order details (editable)
Level	Permission level from 1-100 (editable)
Expiry	Expiration date or "Never" for lifetime licenses (editable)
HWID	Hardware ID if license is bound to specific hardware
Last IP	Most recent connection IP address
Location	Geographic location derived from IP geolocation
Last Login	Timestamp of most recent successful authentication
Device	Device information from last connection
Status	Active, Expired, or Suspended indicator

Search and Filtering

Use the search box to instantly filter licenses by:

• License key (partial or full match)
• Hardware ID (HWID)
• IP address
• Notes or description text

Bans

Block user access using license keys, hardware IDs, IP addresses, or advanced deep hardware tracking with 9-component monitoring.

Ban Types

Atlas supports multiple ban mechanisms for comprehensive access control:

Creating Bans

Manual Ban Creation

1. Click Add Ban in the Bans tab
2. Enter identifier (license key, HWID, or IP address)
3. System automatically detects the ban type
4. Enter reason for the ban (required for record-keeping)
5. Select duration:
   • Permanent - Ban never expires
   • Temporary - Set specific expiration date
6. Click Create Ban to activate

Quick Ban from Licenses

Ban directly from the Licenses table:

1. Locate the license in the Licenses tab
2. Click the ban icon button in the Actions column
3. Confirm the action in the popup dialog
4. Ban is created with reason "Manual ban from dashboard"

Ban Sources

Source	Description
Manual Ban	Created by administrator through dashboard interface
System	Automatic ban triggered by system rules or alert conditions
Security Engine	Cascade ban issued by security alert rules in Settings
Security Engine (Deep Ban)	Advanced deep hardware tracking ban issued automatically

Deep Ban System

Deep bans provide advanced hardware component tracking to prevent ban evasion through HWID spoofing. The system monitors 9 distinct hardware components:

Component	Tracked Information
GPU	Graphics card unique identifier and serial number
Motherboard	Mainboard serial number and manufacturer ID
RAM	Memory module serial numbers and identifiers
CPU	Processor unique ID and serial number
BIOS	Firmware identifier and version signature
Disk	Storage drive serial number
MAC Address	Network adapter hardware address
Monitor	Display device serial number and EDID
System UUID	Unique system identifier from BIOS/UEFI

Managing Bans

Individual Actions

• Revoke/Remove - Delete the ban entry and restore access for the banned identifier

Bulk Operations

Select multiple bans using checkboxes:

• Revoke Selected - Remove multiple bans simultaneously in one action

Search and Filter

Find bans using the search box by:

• IP address (full or partial)
• Hardware ID (HWID)
• License key
• Ban reason text

Ban Information Display

The bans table shows comprehensive ban details:

• Issued By - Creator of the ban (username, System, Security Engine, etc.)
• License Key - Banned license if applicable
• HWID - Banned hardware ID if applicable
• IP Address - Banned IP address if applicable
• Reason - Explanation for why the ban was issued
• Expiry - Expiration date or "Permanent"
• Timestamp - When the ban was created

Logs

View detailed authentication events, system activities, and security alerts with real-time filtering and search capabilities.

Log Event Types

Atlas tracks 9 distinct event types across your authentication system:

Type	Description
SUCCESS	Authentication succeeded - user logged in successfully
AUTH_SUCCESS	Alternative success event type for authentication completion
DENY	Connection denied - authentication failed or was blocked by security rules
BAN	User banned - ban was issued during authentication attempt
ERROR	System error occurred during authentication process
WARNING	Security warning or suspicious activity detected
INFO	Informational event or system message
ADMIN	Administrative action performed through dashboard
SYSTEM	System-level event or internal operation

Log Entry Information

Each log entry contains comprehensive event details:

Field	Content
Timestamp	Exact date and time when the event occurred
Type	Event category (SUCCESS, DENY, ERROR, etc.)
Message	Detailed description of what happened during the event
License Key	License involved in the authentication attempt (if applicable)
IP Address	Connection source IP address
Location	Geographic location derived from IP geolocation
Hardware ID	Device HWID used in authentication (if applicable)
Device	Device information string and platform details
App Hash	Executable SHA-256 hash with description (if hash validation enabled)
Verdict	Final authentication result (Allowed, Denied, Banned, etc.)

Filtering and Search

Type Filter

Filter logs by specific event type using the dropdown selector:

• All - Display all log types
• SUCCESS - Only successful authentications
• DENY - Only denied connection attempts
• ADMIN - Only administrative actions
• BAN - Only ban-related events
• INFO - Only informational messages
• ERROR - Only system errors
• WARNING - Only security warnings

Text Search

Use the search box to filter logs by:

• Message content (partial or full text match)
• License key
• IP address

Log Management Features

Clearing Logs

Remove old logs to keep your dashboard clean and performant. This action permanently deletes log entries and cannot be undone.

Monitor

Track active sessions in real-time, view application statistics, and manage connected users with session control.

Real-time Statistics

The Monitor tab displays 7 key metrics, automatically refreshed every 5 seconds:

Active Session Information

View comprehensive details about connected users:

Field	Information
License Key	License being used in this session
Session ID	Unique identifier for the active session
Status	Online indicator showing real-time connection state
IP Address	Connection source IP address
Hardware ID	Device HWID used for authentication
Device	Device information string and platform
Username	User identifier if provided by application
Connected	Timestamp when session was established
Last Seen	Most recent activity timestamp from this session

Session Management

Individual Session Actions

Action	Function
Kill Session	Immediately terminate a specific user's active session. User is disconnected but can reconnect unless banned or suspended.
Message Session	Send a message to a specific connected user. Message appears in their client application.

Bulk Actions

Action	Function
Message All Active Sessions	Broadcast a message to all currently connected users simultaneously
Terminate All Active Sessions	Force disconnect all users at once. Useful for maintenance windows or emergency shutdowns.

Messaging System

Individual Messages

1. Locate the session in the active sessions table
2. Click Message Session button
3. Enter your message in the dialog
4. Click Send
5. Message is delivered to the user's client application

Broadcast Messages

1. Click Message All Active Sessions
2. Enter your broadcast message
3. Click Send to All
4. All connected users receive the message simultaneously

Manual Refresh

Click Refresh Monitor to immediately update session data and statistics, bypassing the automatic 5-second refresh cycle.

Settings - General

Configure application status, webhooks, file management, and reseller permissions for your application.

Application Information

View your current role and access level:

• Logged in as - Your role (Administrator or Reseller)
• Permissions - Your granted permissions for this application

Application Status

Control global authentication for your entire application with a single toggle:

State	Behavior
Enabled	All authentication requests are processed normally according to your security rules
Disabled	ALL authentication requests are immediately denied - no user can authenticate

Webhook Configuration

Receive real-time HTTP POST notifications when specific events occur in your application.

Adding a Webhook

1. Click Add Webhook
2. Enter your HTTPS URL endpoint (HTTP not supported)
3. Select which events to monitor from the list below
4. Click Save to activate the webhook

Available Webhook Events

Event	Trigger Condition
DENY	Authentication denied or blocked by security rules
ERROR	System error occurred during authentication
SYSTEM	System-level event or internal operation
WARNING	Security warning or suspicious activity detected
BAN	User banned during authentication attempt
AUTH_SUCCESS	Authentication succeeded - user logged in

Managing Webhooks

• Edit - Modify webhook URL or change event subscriptions
• Delete - Remove webhook configuration entirely
• Multiple Webhooks - Add unlimited webhooks for different services

File Slots Management

Upload files to 6 available slots for client download through the Atlas SDK.

File Upload Process

1. Select an empty slot (1-6)
2. Click Upload File
3. Choose your file from disk
4. Toggle Authentication Required:
   • ON - Requires active authenticated session to download
   • OFF - Public access without authentication
5. Click Upload to transfer the file

File Operations

Action	Function
Upload	Add a new file to an empty slot
Replace	Upload a new file to an existing slot (overwrites current file)
Download	Download the file to verify upload integrity
Toggle Auth	Switch between authenticated and public access modes
Delete	Remove file from slot (slot becomes empty)

File Information Display

Each file slot shows:

• Slot number (1-6)
• File name
• File size in bytes/KB/MB
• Upload timestamp
• Authentication requirement status

Reseller Management

Grant other Atlas users limited permissions to manage your application. Resellers can perform specific actions based on the permissions you assign.

Adding a Reseller

1. Click Add Reseller
2. Enter the reseller's Organization ID (found in their account settings)
3. Select permissions using checkboxes from the 19 available options
4. Click Save Reseller Permissions
5. Reseller immediately gains access based on assigned permissions

19 Available Reseller Permissions

Permission	Grants Access To
View Licenses	See license list and details
Add Licenses	Generate new licenses
Delete Licenses	Permanently remove licenses
Edit Licenses	Modify license properties (expiry, note, level)
Reset HWID	Clear hardware ID bindings
Reset IP	Clear IP address bindings
View Bans	See ban list and details
Add Bans	Create new bans
Delete Bans	Revoke existing bans
Edit Bans	Modify ban properties
Files	Manage file slots (upload, delete, download, toggle auth)
Manage Lock Modes	Configure HWID and IP binding security settings
View Logs	Access authentication logs and events
View Stats	See Monitor tab statistics and metrics
Manage Sessions	Kill sessions and send messages to users
App Hash	Add and delete authorized application hashes
Reset App Hash	Clear application hash bindings
Time	Modify license expiry dates
Resellers	Manage other resellers (requires admin review)

Managing Resellers

• Edit Permissions - Modify reseller access rights by changing checkbox selections
• Delete Reseller - Revoke all permissions and remove reseller from your application

Settings - Security Engine

Configure hardware binding, IP restrictions, anti-VPN protection, and authorized application hashes for executable verification.

Security Control Toggles

Enable or disable security features to control license validation behavior:

Hardware ID Binding

Lock licenses to specific hardware on first use:

Mode	Behavior
BIND	License permanently binds to first HWID used. User cannot authenticate from different hardware without reset.
IGNORE	No hardware restriction. License works on any hardware. User can freely change devices.

IP Address Binding

Lock licenses to specific IP address on first use:

Mode	Behavior
BIND	License permanently binds to first IP address. User cannot authenticate from different IP without reset.
IGNORE	No IP restriction. License works from any IP address. User can freely change locations.

Anti-VPN Protection

Block authentication from VPN, proxy, and datacenter IP addresses:

State	Blocked Services
Enabled	Commercial VPN services (NordVPN, ExpressVPN, etc.) Proxy servers (HTTP, SOCKS, transparent) Datacenter IP ranges (AWS, Azure, DigitalOcean) Tor exit nodes Known anonymization services
Disabled	All IP types allowed including VPNs and proxies

Authorized Application Hashes

Whitelist SHA-256 hashes of legitimate executable builds to prevent modified, cracked, or tampered versions from authenticating.

System Operation

1. You add SHA-256 hashes of your official executable builds to the whitelist
2. During authentication, the client calculates and sends its executable hash
3. Atlas verifies the hash against your authorized whitelist
4. Only executables with matching hashes are allowed to authenticate
5. Unrecognized or modified executables are denied immediately

Adding Authorized Hashes

Two methods are available for adding hashes:

Method 1: File Upload (Recommended)

1. Click Add Hash
2. Click Upload File button
3. Select your .exe or .dll file
4. SHA-256 hash is automatically calculated by the browser
5. Add optional description (e.g., "v1.2.3 Release Build", "Steam Version")
6. Click Save to add to whitelist

Method 2: Manual Hash Entry

1. Calculate hash using command-line tools:
   • Windows: certutil -hashfile app.exe SHA256
   • Linux: sha256sum app.exe
   • macOS: shasum -a 256 app.exe
2. Click Add Hash
3. Paste the 64-character hexadecimal hash
4. Add optional description
5. Click Save

Managing Hashes

The authorized hash list displays:

• Hash Value - Full 64-character SHA-256 hash in hexadecimal
• Description - Optional label for identification (version, build type, etc.)
• Added Date - When the hash was added to whitelist
• Delete Action - Remove hash from whitelist (executable immediately blocked)

When to Use Hash Validation

• Prevent Cracks - Block modified executables with patched authentication
• Version Control - Only allow specific application versions to authenticate
• Distribution Security - Ensure users run official builds from authorized channels
• Anti-Tamper - Detect and block executables modified by third parties

Multiple Hash Management

You can add multiple hashes to support:

• Multiple concurrent application versions (v1.0, v1.1, v1.2)
• Different build configurations (Debug, Release, Steam, Standalone)
• Platform-specific executables (Windows x64, Windows x86, Linux)
• Regional or localized builds

Saving Security Settings

After configuring security toggles (HWID Binding, IP Binding, Anti-VPN), click Save Security Settings to apply changes. Settings take effect immediately for all new authentication attempts.

Settings - Messages & Communication

Configure custom messages, error responses, and communication templates for your application users.

Planned Features

Startup Messages

Display custom messages when users successfully authenticate:

• Welcome messages with personalization
• Important announcements and news
• Update notifications for new versions
• Terms of service acceptance reminders
• Promotional messages and offers

Custom Error Messages

Personalize error responses for various authentication failure scenarios:

Error Scenario	Customizable Message
License Expired	Message shown when license has passed expiration date
HWID Mismatch	Message shown when hardware ID doesn't match bound value
IP Mismatch	Message shown when IP address doesn't match bound value
Ban Notification	Message shown to banned users with optional reason display
Version Mismatch	Message shown when executable hash doesn't match whitelist
Maintenance Mode	Message shown when application is disabled
Invalid License	Message shown for non-existent or malformed license keys

Message Templates

Create and manage reusable templates for common communications:

• Session broadcast messages for announcements
• Scheduled maintenance notifications
• Security alert templates
• License renewal reminder messages
• Feature update announcements

Dynamic Variables

Use placeholder variables in messages for personalization:

Variable	Replaced With
{license_key}	User's license key
{expiry_date}	License expiration date
{username}	User's username if provided
{app_name}	Application name
{level}	License permission level
{hwid}	Hardware ID
{ip_address}	Connection IP address

Example Use Cases

Once available, you'll be able to create messages like:

Welcome back, {username}!

Your license level: {level}
Expires: {expiry_date}

Check out our new features in the latest update!

Or custom error messages like:

License Expired

Your license ({license_key}) expired on {expiry_date}.

Please renew at https://your-store.com to continue using {app_name}.
